Touch Screen Surgeon Control Panel

Features:

  • Dimension 640mm X 640mm X 110mm
  • Circuit Voltage 24V DC
  • Digital Clock Green Color Display (1.8” Character HH:MM:SS) (Set-Up-Down)
  • Elapsed Clock Red Color Display (1.8” Character HH:MM:SS) (Start-Stop-Reset)
  • Light Control 3 Channel (2 for peripheral Light & 1 for Plan air) 0-10V Dimming Range
  • Temp/Humd Display room Temp. & Humidity with controlling outputs for both temp. & humd
  • Gas Alarm 5 Channel (4 Gases + 1 vacuum) High / Low / Normal Indication)
  • Hans Free Phone Dialing & Receiving Calls with caller ID

POWER SUPPLY

  • Supply Voltage AC 100-240V, 50/60 Hz
  • Power Consumption 100 watts

TOUCH DISPLAY LED

  • Screen Size 22 inches
  • Resolution 1920x1080 Pixel HD
  • Brightness 450 cd/m2 min.
  • Contrast 1000:1
  • Viewing Angle Horizontal/Vertical;178deg
  • Number of Colors 16.2 Million
  • Response Time 25 ms

SOFTWARE SPECIFICATIONS

  • Booting Time 30 -35 Seconds
  • Operating System Windows
  • Software Version VX 3.0

DIMENSIONS

  • Wall insert oox cut out 615 x 425 x 130 mm
  • Front Frame Panel 665 x 475 mm
  • Panel Weight 15 Kg
  • Packed Box Size 680 x 500 x 195 mm
  • Packed Box Weight 17 Kg

EMBEDDED PC DURATHON TECHNOLOGY

  • CPU Intel Celeron 2.4 Ghz
  • RAM 2 GB
  • Storage 60 GB SSD
  • Interfaces 4xUSB, 2xSerial, 1xLAN
  • Graphic VGA, HDMI
